Description of ZL Series Drum Granulator:
This ZL drum granulator is the key equipment for compound fertilizer industry, and quite appropriate for cold and hot, high and low concentration granulation of compound fertilizers.
Parameters of ZL Series Drum Granulator:
| Specification | Output (t/h) | Rotating speed of cylinder | Inclination angle ofcylinder | Main motor | Main speed reducer | Weight (kw) | |
| Model | Power | ||||||
| 1.4×4.0 | 4.0-80 | 13.2 | 2.0° | Y160M-6 | 7.5 | JZQ400 | 8000 |
| 1.4×6.0 | 4.0-8.0 | 13.2 | 2.0° | Y160M-6 | 7.5 | JZQ400 | 9000 |
| 1.6×4.0 | 5.0-10 | 12.0 | 2.5° | Y160L-6 | 11.0 | ZLY125-12.5 | 10000 |
| 1.6×6.0 | 5.0-10 | 12.0 | 2.5° | Y160L-6 | 11.0 | ZLY125-12.5 | 11000 |
| 1.8×6.0 | 6.0-12 | 8.2 | 2.5° | Y180M-4 | 15.0 | ZSY200-22.4 | 16000 |
| 1.8×8.0 | 8.0-16 | 8.2 | 2.5° | Y200L-6 | 22.0 | ZL60-25 | 17600 |
| 2.0×6.0 | 10-20 | 10.5 | 2.5° | Y180L-4 | 30.0 | ZL60-25 | 21800 |
| 2.0×8.0 | 12-24 | 11.0 | 2.5° | Y180L-4 | 30.0 | ZL60-25 | 25800 |
| 2.2×6.0 | 15-30 | 11.0 | 2.5° | Y180L-4 | 30.0 | ZL60-25 | 25500 |
| 2.2×8.0 | 18-35 | 11.0 | 2.5° | Y200M-6 | 37.0 | ZLY75-20 | 28200 |
| 2.4×7.0 | 19-40 | 8.6 | 3.5% | Y250M-6 | 37.0 | ZLY250 | 35200 |
| 2.4×8.0 | 20-40 | 9.7 | 3.5% | Y280M-6 | 55.0 | ZL65-25 | 39200 |
| 2.6×6.0 | 22-50 | 9.7 | 2.5° | Y250M-6 | 37.0 | ZLY250 | 36800 |
| 2.6×8.0 | 25-50 | 8.8 | 2.5° | Y280M-6 | 55.0 | ZSY224-25 | 40600 |
| 2.8×8.0 | 30-60 | 5.2 | 3.5% | Y315M-6 | 90.0 | ZSY280-22.4 | 52600 |
| 2.8×10 | 40-80 | 5.2 | 3.5% | Y315M-6 | 90.0 | ZSY315-25 | 58500 |
| 3.0×8.0 | 40-80 | 8.8 | 2.5° | Y315M-6 | 90.0 | ZSY315-16 | 59400 |
| 3.0×10 | 45-90 | 9.17 | 2.5° | Y315L-6 | 110 | ZLY280-31.5 | 69500 |
| 3.2×8.0 | 40-80 | 11.0 | 2.5° | Y315L-6 | 110 | ZLY280-31.5 | 70000 |
| 3.2×10 | 45-90 | 11.0 | 2.5° | Y315L-6 | 110 | ZLY280-31.5 | 74200 |
| 3.4×8.0 | 50-100 | 9.14 | 2.5° | Y315L1-4 | 160 | ZLY315-20 | 80000 |
| 3.4×10 | 55-110 | 9.14 | 2.5° | Y315L1-4 | 160 | ZLY315-20 | 82800 |
| 3.7×8.0 | 70-140 | 11.0 | 2.5° | Y315M-4 | 185 | ZSY355-20 | 92500 |
Note:
1. Rubber plate has been used as lining.
2. Temperature of materials to be granulated ranges from 45℃ to 80℃.
3. Its productivity varies with different materials and process conditions.
=====================================================================================================================
